V6 Series High Performance Servo Motor
V6 series high performance servo motor has independent intellectual property rights, using high performance rare earth permanent magnet materials, with small size, high power density, strong overload capacity, low cogging torque, low noise and exquisite appearance and other outstanding advantages.
Features: High performance, high overload, support a variety of encoders.
Technical Parameter
電压Voltage |
220V |
|||
型号Model MV6M- |
02A |
04A |
||
机座号 Size |
□60 |
|||
额定输出Rated Output (KW) |
0.2 |
0.4 |
||
额定转矩Rated Torque*1 (Nm) |
0.64 |
1.27 |
||
最大转矩Maximum Torque (Nm) |
2.24 |
4.45 |
||
额定電流Rated Current (A) |
1.5 |
2.54 |
||
最大電流Maximum Current (A) |
5.7 |
9.3 |
||
额定转速Rated Speed (rpm) |
3000 |
|||
最高转速Maximum Speed (rpm) |
6000 |
|||
力矩系数Torque Coefficient (Nm/A) |
0.427 |
0.512 |
||
線反電势系数Linear Back-EMF Coefficient (V/Krpm) |
28.6 |
33.0 |
||
20℃时線電阻 Line Resistance at 20℃ (Ω) |
5.6 |
2.9 |
||
20℃时線電感 Line Inductance at 20℃ (mH) |
10.1 |
5.85 |
||
转子极数Rotor Pole |
10 |
|||
转子转动惯量Rotor Moment of Inertia(10-4kg·m2) |
0.27 |
0.51 |
||
最大径向拉力 Maximum Radial Tension(N) |
245 |
|||
最大轴向拉力 Maximum Shaft Tension(N) |
74 |
|||
保护结构Protective Structure*2 |
全封闭自冷Fully Enclosed & Self-Cooling IP65 |
|||
保持 Maintain Brake Specifications |
额定電压Rated Voltage DC (V) |
24±10% |
||
功率Power (W) |
7.3 |
|||
静保持转矩Static Holding Torque (Nm) |
>1.5 |
|||
20℃时電阻 Resistance at 20℃ (Ω) |
78.9 |
|||
20℃时额定電流Rated Current at 20℃ (A) |
0.3±10% |
|||
吸引时间 Attraction Time (ms) |
60 |
|||
释放时间 Release Time (ms) |
20 |
|||
容许负载转动惯量 Allowable Load Moment of Inertia |
10倍以下 Less than 10 times |
Overall Dimension
Torque-Speed Characteristic Curve
Note: A (instantaneous working area) B (continuous working area)
